SLS Metal 3D Printing

EOS M 300

1
EOS M 300
EOS M 300
Technical Data Details
Build Volume 300 x 300 x 425 mm (11.8 x 11.8 x 17.1 in)
Laser Type Yb-fiber laser; 1 x 400 W
Precision Optics 4 F-theta-lens(es); 1 High-speed scanner(s)
Scan Speed Up to 7.0 m/s (23.0 ft/s)
Focus Diameter Approx. 100 µm (0.00394 in)
Power Supply 3 x 63 A
Power Consumption Max. 19.6 kW / Typical 16.0 kW
Compressed Air Supply 7 Bar; 15 m³/h (102 psi; 530 ft³/h)
Machine Dimensions 5221 x 2680 x 2340 mm (205.6 x 105.5 x 92.1 in)
Recommended Installation Space Min. 8800 x 5200 x 3500 mm (346.5 x 204.7 x 137.8 in)
Weight Approx. 5500 kg (12125 lbs)
Software EOS BUILD , EOS SMART MONITORING , EOS SYSTEM SUITE
