Special features:
1. Swing over bed ⌀515mm.
2. Max. turning diameter ⌀250mm.
3. Max. turning length 600mm.
4. Choice of 8, 12, 23 station turret or power turret
5. Modular design provides a variety of options for cost effective combination from bar feeder, parts conveyor, tool presetter, bar puller to genie robot.
6. 51.5mm bar capacity.
7. FANUC α P22i wide speed range, spindle drive provides 11/15KW output.
8. Meehanite base, saddle and headstock casting.
9. Precision heavy duty linear ball guide ways.
10. Choice of FANUC or Siemens CNC control.
11. The smallest footprint in its class.
12. Automatic lubrication system.
13. Straight bed construction.
14. Bed slideways are fitted with linear motion guides.
